Patent No. 4591788 Magnetic field sensing device



Patent No. 4591788  Magnetic field sensing device (Mohri, et al., May 27, 1986)

Abstract

A magnetic field sensing device for sensing low levels of magnetic intensity is composed of a ribbon-shaped strip of amorphous magnetic material having at least one twist along the length thereof between the ends of the strip. Subsequent to imparting the desired number of twists to the strip, the strip is supported in the twisted condition. The device is capable of generating a pulse in response to the presence of an external magnetic field similar to the Wiegand wire effect.

Notes:

Magnetic field sensing device. Filed September 1982, granted May 1986. Says it is capable of detecting magnetic fields in the .001 Hz to 6 Hz frequency range. Basically just detects that the magnetic field is there and sounds like something from a Junior High or High School general science class demonstration.

BACKGROUND OF THE INVENTION

The present invention is directed to a magnetic field sensing device and more specifically to a twisted, ribbon-shaped strip of amorphous magnetic material which is supported in the twisted condition and exhibits an effect similar to a Wiegand effect.

A Wiegand wire is a bistable magnetic device having specific characteristics obtainable by processing a thin ferromagnetic wire to form a central relatively "soft" core portion and an outer relatively "hard" magnetized shell portion with relatively low and high coercivities respectively. Such a bistable ferromagnetic wire is disclosed in the Wiegand U.S. Pat. No. 3,820,090, granted June 25, 1974 and entitled "Bistable Magnetic Device". The magnetized shell portion is operable for magnetizing the core portion in a first direction, the magnetization of the core portion is reversible by application of a separate magnetic field and the shell portion is operable to remagnetize the core portion in a first direction upon removal of the separate magnetic field. As a result of the changing magnetic field, there is a net change in the flux outside of the wire and an appropriately placed pick-up coil will generate a pulse-shaped voltage having a peak value and a narrow width with no relation to the changing rate of the magnetic field. Thus, the Wiegand wire is useful as a magnetic sensor. However, a conventional Wiegand wire is capable of only being able to detect a fairly high external magnetic field.

German Offenlegungsschrift No. 28 06 249 discloses a transmitter for emitting an electrical signal during the magnetic reversal of a ferromagnetic wire within a coil wherein the wire is kept under tensile stress and/or torsional stress.
